A stereo integrated amplifier with a built-in ESS Sabre DAC, class-A/B power stage and headphone output, aimed at listeners who play mostly digital sources. It delivers 125 W per channel into 8 ohms and takes Bluetooth aptX HD, USB, S/PDIF and AES inputs.
- 125 W/ch at 8 ohms, nearly 250 W/ch at 4 ohms, stable to 2 ohms
- ESS Sabre 32-bit DAC, PCM to 384 kHz/32 bit and DSD to 11.2 MHz
- MQA decoding on all digital inputs, including USB
- Bluetooth input with aptX HD
- Class-A headphone stage on a front-panel 6.35 mm jack
- Ethernet, RS-232, 12 V trigger and web-page setup
Fotod
8Kuulutused
Sellel mudelil pole veel kuulutusi
Kui keegi müüb mudeli 5802, ilmuvad kuulutused ja müügiajalugu siia.
Müü samasuguneKirjeldus
The № 5802 combines a preamplifier, a DAC and a stereo power amplifier in one chassis. The DAC section is built around a 32-bit ESS Sabre converter with jitter elimination and a discrete, fully balanced current-to-voltage stage. It handles PCM up to 32 bit/384 kHz and DSD up to 11.2 MHz, and it decodes MQA on all digital inputs, including asynchronous USB.
The amplifier channels are fully discrete, direct-coupled class A/B designs, fed by an oversized toroidal transformer of more than 500 VA with separate secondary windings for each channel. Output is rated at 125 W per channel into 8 ohms and nearly 250 W into 4 ohms, with stable operation down to 2 ohms. A class-A analog stage drives the front-panel headphone jack, and variable RCA line outputs allow system expansion.
Digital inputs are AES, USB, two coaxial and two optical S/PDIF, plus a Bluetooth receiver with aptX HD. For control and integration it has Ethernet, RS-232, a 12 V trigger input and output, and an IR input. It can be set up through a built-in webpage and operated with the aluminum IR remote or the 5Kontrol app on iOS and Android.
Video
Tehnilised andmed
- Bränd
- Mark Levinson
- Mudel
- 5802
- Kategooria
- Hi-Fi ja kodune heli › Võimendid
Inputs
- AES/EBU input
- 1 balanced (XLR)
- USB input
- 1 asynchronous USB 2.0 (USB-B)
- Coaxial S/PDIF inputs
- 2 (RCA)
- Optical S/PDIF inputs
- 2 (Toslink)
- Bluetooth
- Audio input with aptX HD
Outputs
- Line outputs
- 1 pair single-ended RCA, variable
- Headphone output
- 1 x 1/4-inch/6.35 mm jack (front panel)
- Loudspeaker outputs
- 2 pairs high-current binding posts with banana sockets
Audio
- DAC
- ESS Sabre 32-bit, Precision Link II
- PCM support
- Up to 32 bit/384 kHz
- DSD support
- Up to 11.2 MHz
- MQA
- Full decoding on all digital inputs
- Amplifier class
- Class A/B, fully discrete, direct-coupled
- Output power
- 125 W/channel at 8 ohms; nearly 250 W/channel at 4 ohms
- Load stability
- Stable down to 2 ohms
Connectivity
- Ethernet
- 1 x RJ-45
- RS-232
- 1 x DB9
- 12 V trigger
- 1 input and 1 output, 3.5 mm jack; output 100 mA max
- IR input
- 1 x 3.5 mm jack
- Control
- 5Kontrol app (Android, iOS), IR remote, web page setup
Power
- Mains voltage
- 100 VAC, 115 VAC or 230 VAC, factory set
- Standby, Green mode
- <0.4 W
- Power on, quiescent
- 95 W
- Power on, maximum
- 500 W
Physical
- Dimensions (H x W x D)
- 145 x 438 x 507 mm (5.72 x 17.25 x 19.98 in)
- Weight
- 27.6 kg (61 lbs)
- Packed weight
- 32.6 kg (72 lbs)
In the box
- Remote control
- Aluminum IR remote
